Back to list Non-metallic sensing cable
Note: The outer sheath material, color and printing information of the optical cable can be customized according to the requirements of customers

The structure from inside to outside is:

Optical fiber:0..9mm tight-packed optical fiber x 1 core;

Aramid fiber:4 strands×1100D;

Outer sheath of optical cable:  LSZH.

  • Cable performance
  • Application
  • Fiber properties
  • Color-coded
  • Other information
Cable performance

Cable type

Unit

DJ-GYFJH-1S

Fiber size

mm

0.90±0.05



Inner sheath material

/

PVC / LSZH / HYTREL / NYLON



Aramid fiber

Detex

1100



Sheath Outer Diameter

mm

3.20±0.10



Outer sheath material

/

polyvinyl chloride (PVC)

Low Smoke Zero Halogen (LSZH)

Polyurethane
(PU)



 Temperature range

-20~+70

-40~+85

-40~+90



Cable weight

Kg/km

8



Bending radius

mm

Dynamic 20D Static 10D



Tensile

N

Long-term 200 Short-term 400



Crush

N/10cm

Long-term 200 Short-term 400


Application
Anti-rat bite Anti-twist
Oil field Tensile
Wind energy The pipeline
Perimeter Direct burial
Oil tank Overhead
Subway, tunnel Waterproof
Coal mine Fireproof
Fiber properties

Cable type

Unit

DJ-GYFJH-1S

Fiber size

mm

0.90±0.05

Inner sheath material

/

PVC


Color-coded

1

2

3

4

5

6

7

8

9

10

11

12

Blue

Orange

Green

Brown

Gray

White

Red

Black

Yellow

Purple

Pink

Dark green
