Back to list Stainless Steel Oil Field Sensing Optical Cable (Aluminum)
Note: The outer sheath material, color and printing information of the optical cable can be customized according to the requirements of customers

From inner to outer:

Optical fiber: normal temperature or high temperature bare optical fiber;

Fiber optic composite stainless steel tube: OD 2.8mm;

Aluminum alloy tube: OD 4.6mm;

Stainless steel tube: OD 6.35mm.



  • Cable performance
  • Application
  • Fiber properties
  • Color-coded
  • Other information
Cable performance

Cable type

unit

DJ-GTSXLG-1~12S

Outer diameter of optical fiber composite stainless steel tube

mm

2.80±0.10

Aluminum alloy tube outer diameter

mm

4.60±0.10

Stainless steel tube outer diameter

mm

6.35±0.10

Temperature range

-60~+350 (depending on fiber temperature characteristics)

Storage temperature

-20~+80

Cable weight

Kg/km

145

Tensile

N

Long-term 5000 Short-term 10000

Crush

N/10cm

Long term 10000 Short term 20000


Application
Anti-rat bite Anti-twist
Oil field Tensile
Wind energy The pipeline
Perimeter Direct burial
Oil tank Overhead
Subway, tunnel Water proof
Coal mine Fireproof
Fiber properties
Cable type Unit DJ-GTSXLG-1~12S

Fiber Size

mm 0.25±0.01
Color-coded

1

2

3

4

5

6

7

8

9

10

11

12

Blue

Orange

Green

Brown

Gray

White

Red

Black

Yellow

Purple

Pink

Dark green
