Back to list 200GBASE-SR4 QSFP56 Multimode Optical Module 850nm 100m DOM MTP/MPO-12
1. The maximum power consumption is only 5W, with built-in Inphi chip

2. It has been rigorously tested in the target switch to ensure its excellent performance, high quality and reliability

3. The design adopts the QSFP56 packaging form that meets the hot-swappable standard to meet the needs of modern data centers

4. The high-speed electrical interface of the optical module complies with the IEEE 802.3bs standard and the QSFP56 MSA CMIS V4.0 specification, ensuring compatibility with various devices

Model name

QSFP-SR4-200G

Package type

QSFP56

Wavelength

850nm

Interface

MTP/MPO-12 UPC

Transmitter Type

VCSEL 850nm

Transmitted optical power

-3~3dBm

Power budget

3.5dBm

Typical power consumption

≤5W

Data diagnosis(DDM/DOM)

Support

CDR(Clock Data Recovery)

Built-in transmitter and

receiver CDR

Technical Agreement

IEEE 802.3bsQSFP56 MSA

SFF-8665CMIS Rev 4.0


  • Cable performance
  • Application
  • Fiber properties
  • Color-coded
  • Other information
Cable performance

Model name

QSFP-SR4-200G

Brand

Dong Jie

Package type

QSFP56

Transmission rate

200Gbps

Wavelength

850nm

Transmission distance

70m@OM3/100m@OM4

Interface

MTP/MPO-12 UPC

Fiber Type

MultiMode MMF

Transmitter Type

VCSEL 850nm

Receiver Type

PIN

Transmitted optical power

-3~3dBm

Receive sensitivity

-6.5 dBm

Power budget

3.5dBm

Receive overload

5dBm

Typical power consumption

≤5W

Extinction ratio

3dB

Data diagnosis(DDM/DOM)

Support

Commercial temperature range

070℃(32158F)

CDR(Clock Data Recovery)

Built-in transmitter and receiver CDR

FEC Function

Suppor tRS-FEC

Technical Agreement

IEEE 802.3bsQSFP56 MSASFF-8665CMIS Rev 4.0

Warranty

5 years

Application

Model name

QSFP-SR4-200G

Brand

Dong Jie

Package type

QSFP56

Transmission rate

200Gbps

Wavelength

850nm

Transmission distance

70m@OM3/100m@OM4

Interface

MTP/MPO-12 UPC

Fiber Type

MultiMode MMF

Transmitter Type

VCSEL 850nm

Receiver Type

PIN

Transmitted optical power

-3~3dBm

Receive sensitivity

-6.5 dBm

Power budget

3.5dBm

Receive overload

5dBm

Typical power consumption

≤5W

Extinction ratio

3dB

Data diagnosis(DDM/DOM)

Support

Commercial temperature range

070℃(32158F)

CDR(Clock Data Recovery)

Built-in transmitter and receiver CDR

FEC Function

Suppor tRS-FEC

Technical Agreement

IEEE 802.3bsQSFP56 MSASFF-8665CMIS Rev 4.0

Warranty

5 years

Fiber properties

Model name

QSFP-SR4-200G

Brand

Dong Jie

Package type

QSFP56

Transmission rate

200Gbps

Wavelength

850nm

Transmission distance

70m@OM3/100m@OM4

Interface

MTP/MPO-12 UPC

Fiber Type

MultiMode MMF

Transmitter Type

VCSEL 850nm

Receiver Type

PIN

Transmitted optical power

-3~3dBm

Receive sensitivity

-6.5 dBm

Power budget

3.5dBm

Receive overload

5dBm

Typical power consumption

≤5W

Extinction ratio

3dB

Data diagnosis(DDM/DOM)

Support

Commercial temperature range

070℃(32158F)

CDR(Clock Data Recovery)

Built-in transmitter and receiver CDR

FEC Function

Suppor tRS-FEC

Technical Agreement

IEEE 802.3bsQSFP56 MSASFF-8665CMIS Rev 4.0

Warranty

5 years
