QSFP-200G-FR4 compatible with 200GBASE-FR4 QSFP56 single mode optical module 1310nm 2km DOM duplex LC-Accessories

Back to list QSFP-200G-FR4 compatible with 200GBASE-FR4 QSFP56 single mode optical module 1310nm 2km DOM duplex LC

1. Maximum power consumption is 6.5W, equipped with Oclaro chip,
2. Package is QSFP56 package, hot-swappable
3. High-speed electrical interface complies with IEEE 802.3bs standard and IEEE 802.3cd
4. Complies with QSFP56 MSA CMIS V4.0 specification
5. Supports 4x50G PAM4 retiming 200GAUI-4 electrical interface
6. Equipped with digital optical monitoring function, providing powerful diagnostic capabilities
7. Complies with Class 1 FDA laser safety level

Model name	QSFP-200G-FR4
Package type	QSFP56
Wavelength	1271nm、1291nm、1311nm、1331nm
Interface	Duplex LC
Transmitter Type	DFB
Transmitted optical power	-4.2~4.7 dBm
Power budget	4 dBm
Typical power consumption	≤6.5W
Data diagnosis(DDM/DOM)	Support
Technical Agreement	IEEE 802.3cd、IEEE 802.3bs、QSFP56 MSA SFF-8665、SFF-8024、SFF-8679

Cable performance
Application
Fiber properties
Color-coded
Other information

Cable performance

Model name	QSFP-200G-FR4	Brand	Dong Jie
Package type	QSFP56	Transmission rate	200Gbps
Wavelength	1271nm、1291nm、1311nm、1331nm	Transmission distance	2km
Interface	Duplex LC	Fiber Type	Single Mode SMF
Transmitter Type	DFB	Receiver Type	PIN
Transmitted optical power	-4.2~4.7 dBm	Receive sensitivity	<-8.2 dBm
Power budget	4 dBm	Receive overload	4.7 dBm
Typical power consumption	≤6.5W	Extinction ratio	>3.5 dB
Data diagnosis(DDM/DOM)	Support	Commercial temperature range	0～70℃(32～158F)
Technical Agreement	IEEE 802.3cd、IEEE 802.3bs、QSFP56 MSA SFF-8665、SFF-8024、SFF-8679	Warranty	5 years

Application

Model name	QSFP-200G-FR4	Brand	Dong Jie
Package type	QSFP56	Transmission rate	200Gbps
Wavelength	1271nm、1291nm、1311nm、1331nm	Transmission distance	2km
Interface	Duplex LC	Fiber Type	Single Mode SMF
Transmitter Type	DFB	Receiver Type	PIN
Transmitted optical power	-4.2~4.7 dBm	Receive sensitivity	<-8.2 dBm
Power budget	4 dBm	Receive overload	4.7 dBm
Typical power consumption	≤6.5W	Extinction ratio	>3.5 dB
Data diagnosis(DDM/DOM)	Support	Commercial temperature range	0～70℃(32～158F)
Technical Agreement	IEEE 802.3cd、IEEE 802.3bs、QSFP56 MSA SFF-8665、SFF-8024、SFF-8679	Warranty	5 years

Fiber properties

Model name	QSFP-200G-FR4	Brand	Dong Jie
Package type	QSFP56	Transmission rate	200Gbps
Wavelength	1271nm、1291nm、1311nm、1331nm	Transmission distance	2km
Interface	Duplex LC	Fiber Type	Single Mode SMF
Transmitter Type	DFB	Receiver Type	PIN
Transmitted optical power	-4.2~4.7 dBm	Receive sensitivity	<-8.2 dBm
Power budget	4 dBm	Receive overload	4.7 dBm
Typical power consumption	≤6.5W	Extinction ratio	>3.5 dB
Data diagnosis(DDM/DOM)	Support	Commercial temperature range	0～70℃(32～158F)
Technical Agreement	IEEE 802.3cd、IEEE 802.3bs、QSFP56 MSA SFF-8665、SFF-8024、SFF-8679	Warranty	5 years

Color-coded

Other information
