Back to list OSFP 800GBASE-2FR4 Optical Module PAM4 1310nm 2km DOM Dual LC/UPC Duplex Single Mode

1. Maximum power consumption is 16.5W, equipped with Broadcom 7nm DSP
2 High-speed connection standards are IEEE 802.3c and IEEE 802.3cu-2021
3. Meets hot-swappable OSFP MSA standards
4. Higher port density is achieved by 2x400G breakouts
5. Provides higher bandwidth for hyperscale data centers and cloud infrastructure

Model	OSFP-800G-2FR4
Package form	OSFPTop band heat sinkHeat sheet
Wavelength	1271nm,1291nm,1311nmand1331nm
Connector	DualLCDuplex/UPC
Transmitter Type	EML
TXPower	-3.2~4.4dBm
Power Budget	4dB
Power consumption	≤16.5W
DDM/DOM	Support
Agreement	IEE802.3ck,IEEE 802.3cu,OSFP MSA
Agreement	IEE802.3ck,IEEE 802.3cu,OSFP MSA

Cable performance
Application
Fiber properties
Color-coded
Other information

Cable performance

Model	OSFP-800G-2FR4	Brand	DongJie
Package form	OSFPTop band heat sinkHeat sheet	Maximum data transmission rateRate	850Gbps (8x 106.25Gbps)
Wavelength	1271nm,1291nm,1311nmand1331nm	Maximum cable transmission distance	2km
Connector	DualLCDuplex/UPC	Fiber	Single Mode
Transmitter Type	EML	Receiver Type	PIN
TXPower	-3.2~4.4dBm	Minimum Receive Power	-7.2dBm
Power Budget	4dB	Receive Overload	4.4dBm
Power consumption	≤16.5W	Extinction ratio	>3.5dB
DDM/DOM	Support	Commercial temperature range	0~70°℃(32~158°F)
Agreement	IEE802.3ck,IEEE 802.3cu,OSFP MSA	Warranty	5Years

Application

Model	OSFP-800G-2FR4	Brand	DongJie
Package form	OSFPTop band heat sinkHeat sheet	Maximum data transmission rateRate	850Gbps (8x 106.25Gbps)
Wavelength	1271nm,1291nm,1311nmand1331nm	Maximum cable transmission distance	2km
Connector	DualLCDuplex/UPC	Fiber	Single Mode
Transmitter Type	EML	Receiver Type	PIN
TXPower	-3.2~4.4dBm	Minimum Receive Power	-7.2dBm
Power Budget	4dB	Receive Overload	4.4dBm
Power consumption	≤16.5W	Extinction ratio	>3.5dB
DDM/DOM	Support	Commercial temperature range	0~70°℃(32~158°F)
Agreement	IEE802.3ck,IEEE 802.3cu,OSFP MSA	Warranty	5Years

Fiber properties

Model	OSFP-800G-2FR4	Brand	DongJie
Package form	OSFPTop band heat sinkHeat sheet	Maximum data transmission rateRate	850Gbps (8x 106.25Gbps)
Wavelength	1271nm,1291nm,1311nmand1331nm	Maximum cable transmission distance	2km
Connector	DualLCDuplex/UPC	Fiber	Single Mode
Transmitter Type	EML	Receiver Type	PIN
TXPower	-3.2~4.4dBm	Minimum Receive Power	-7.2dBm
Power Budget	4dB	Receive Overload	4.4dBm
Power consumption	≤16.5W	Extinction ratio	>3.5dB
DDM/DOM	Support	Commercial temperature range	0~70°℃(32~158°F)
Agreement	IEE802.3ck,IEEE 802.3cu,OSFP MSA	Warranty	5Years

Color-coded

Other information
