| Model | OSFP-800G-2FR4 |
| Package form | OSFPTop band heat sinkHeat sheet |
| Wavelength | 1271nm,1291nm,1311nmand1331nm |
| Connector | DualLCDuplex/UPC |
| Transmitter Type | EML |
| TXPower | -3.2~4.4dBm |
| Power Budget | 4dB |
| Power consumption | ≤16.5W |
| DDM/DOM | Support |
| Agreement | IEE802.3ck,IEEE 802.3cu,OSFP MSA |
| Jumper Networks Compatible | QDD-2×400G-DR4 | Brand | DongJie |
| Package type | QSFP-DD | Maximum data transmission rate | 850Gbps (8x106.25Gbps) |
| Wavelength | 1310nm | Maximum Cable TransmissionDistance | 500m |
| Connector | MTP/MPO-16 APC | Fiber optic | Single mode |
| Transmitter Type | EML | Receiver Type | PIN |
| TX Power | -2.9~4.0dBm | Minimum received power | -5.9dBm |
| Power budget | 3dB | Receive Overload | 4dBm |
| Power consumption | ≤16.5W | Extinction ratio | >3.5dB |
| Packaging technology | COB (Chip on board) Packaging | Modulation Format | PAM4 |
| CDR (Clock and Data Recovery) | TX and RXBuilt-inDSP | Built-in FEC | Yes |
| Agreement | IEEE 802.3cu、IEEE 802.3ck、 | Warranty | 5 years |
| QSFP56 MSA HW、Rev 6.01, CMIS 5.0 |
| Jumper Networks Compatible | QDD-2×400G-DR4 | Brand | DongJie |
| Package type | QSFP-DD | Maximum data transmission rate | 850Gbps (8x106.25Gbps) |
| Wavelength | 1310nm | Maximum Cable TransmissionDistance | 500m |
| Connector | MTP/MPO-16 APC | Fiber optic | Single mode |
| Transmitter Type | EML | Receiver Type | PIN |
| TX Power | -2.9~4.0dBm | Minimum received power | -5.9dBm |
| Power budget | 3dB | Receive Overload | 4dBm |
| Power consumption | ≤16.5W | Extinction ratio | >3.5dB |
| Packaging technology | COB (Chip on board) Packaging | Modulation Format | PAM4 |
| CDR (Clock and Data Recovery) | TX and RXBuilt-inDSP | Built-in FEC | Yes |
| Agreement | IEEE 802.3cu、IEEE 802.3ck、 | Warranty | 5 years |
| QSFP56 MSA HW、Rev 6.01, CMIS 5.0 |
| Jumper Networks Compatible | QDD-2×400G-DR4 | Brand | DongJie |
| Package type | QSFP-DD | Maximum data transmission rate | 850Gbps (8x106.25Gbps) |
| Wavelength | 1310nm | Maximum Cable TransmissionDistance | 500m |
| Connector | MTP/MPO-16 APC | Fiber optic | Single mode |
| Transmitter Type | EML | Receiver Type | PIN |
| TX Power | -2.9~4.0dBm | Minimum received power | -5.9dBm |
| Power budget | 3dB | Receive Overload | 4dBm |
| Power consumption | ≤16.5W | Extinction ratio | >3.5dB |
| Packaging technology | COB (Chip on board) Packaging | Modulation Format | PAM4 |
| CDR (Clock and Data Recovery) | TX and RXBuilt-inDSP | Built-in FEC | Yes |
| Agreement | IEEE 802.3cu、IEEE 802.3ck、 | Warranty | 5 years |
| QSFP56 MSA HW、Rev 6.01, CMIS 5.0 |
